Geographic Positioning System Teaching Equipment

Geographic Positioning System (GPS) is designed for tracking, positioning and elevation measurement for various engineering applications. The system provides accurate location information and supports practical field measurement and surveying activities.

The GPS features a high-sensitivity receiver with approximately 3 m positioning accuracy, a barometric altimeter for elevation measurement and a tilt-compensated 3-axis compass for directional reference. Bluetooth connectivity and 2 GB internal memory support convenient data handling and field operation.

The compact and rugged instrument features an IPX7 water rating and a color TFT display. An internal rechargeable lithium-ion battery provides extended operating time depending on the selected tracking and power-saving mode.

The device also supports interactive SOS functions and text messaging to SMS and email for communication and emergency applications.

Manufactured by Atico Export with a focus on precision, durability and consistent performance for technical education and practical training applications.

Physical Specifications :

• Dimensions: 6.8 × 16.4 × 3.8 cm
• Weight: 213 g

Display :

• Display size: approximately 3.5 × 4.7 cm
• Diagonal display size: 2.31" (5.9 cm)
• Display resolution: approximately 200 × 265 pixels
• Display type: Transflective color TFT

Battery :

• Battery type: Rechargeable internal lithium-ion
• Battery life: up to 100 hours at 10-minute tracking mode
• Battery life: up to 75 hours with 10-minute tracking and 1-second logging
• Battery life: up to 30 days at 30-minute internal power-save mode
• Standby mode: up to 3 years

• Suitable for tracking, positioning and elevation measurement
• High-sensitivity GPS receiver
• Positioning accuracy: approximately 3 m
• Barometric altimeter
• Tilt-compensated 3-axis compass
• Bluetooth compatible
• 2 GB internal memory
• IPX7 water rating
• Color TFT display
• Interactive SOS function with 24/7 search and rescue monitoring
• Send and receive text messages to SMS and email
