Geothermal Probe with Heat Pump Principle Teaching Equipment

Geothermal Probe with Heat Pipe Principle is designed for practical demonstration and investigation of the operation of a geothermal probe based on the heat pipe principle. The system features a glass heat pipe with a transparent temperature-control jacket for direct observation of the heat transfer process.

Water is used as the working medium for heat dissipation in the heat exchanger. The working medium can be supplied through the laboratory water network or a water chiller to maintain a maximum water temperature of 16 °C.

The setup includes a U-tube geothermal probe made of copper, heating circuits, pumps, a water tank and sand container for practical investigation of geothermal heat transfer. The system also allows simulation of the energy balance of a heat pump.

Temperature and flow rate can be measured during experiments, while PC-based software supports data acquisition via USB and analysis of experimental results.

Designed and manufactured by Atico Export to meet the practical requirements of modern technical education laboratories.

Heat Pipe :

• Length: approximately 1000 mm
• External diameter of heat pipe: approximately 56 mm
• External diameter of temperature-control jacket: approximately 80 mm

Heating Circuit :

• Heater output: 2 kW
• Pump maximum flow rate: 1.9 m³/h
• Pump power consumption: 58 W

Geothermal Probe :

• Type: U-tube geothermal probe
• Material: Copper
• Length: approximately 1000 mm

Pump for Thermal Response Test :

• Flow rate: 4.8–28.2 L/h
• Power consumption: maximum 60 W

Water Tank Heating Element :

• Output: 100 W

Sand Container Heating Element :

• Output: 50 W

Refrigerant :

• Refrigerant: R1233zd
• GWP: 1
• Filling volume: 2.3 kg
• CO₂ equivalent: 0 t

Measuring Ranges :

• Temperature of heating element in sand sample: 0–250 °C
• Flow rate: 0.4–6 L/min

Power and Electrical :

• Mains connection: 230 V, 50 Hz, 1 phase

Dimensions and Weight :

• L × W × H: approximately 2170 × 790 × 1900 mm
• Weight: approximately 250 kg

Required for Operation :

• Water connection: minimum 360 L/h
• Maximum water temperature: 16 °C
• Drain or suitable water chiller
• PC with Windows recommended

• Demonstration of the operation of a geothermal probe using the heat pipe principle
• Glass heat pipe with transparent temperature-control jacket
• Water as working medium for heat dissipation in the heat exchanger
• Working medium supply via laboratory water network or water chiller
• Maximum water temperature: 16 °C
• Simulation of the energy balance of a heat pump
• U-tube geothermal probe made of copper
• Heating circuit with heater and pump
• Thermal response test
• Heating element in water tank
• Heating element in sand container
• Refrigerant: R1233zd
• GWP: 1
• PC-based data acquisition via USB
• Windows-compatible software
