Liquid Heating Engineering Teaching Equipment

Liquid Heating Engineering is designed for practical laboratory studies of heat transfer processes in liquids and heat exchange systems. The equipment provides a comprehensive platform for investigating the thermal behavior of liquids, heat transfer coefficients, heat exchanger performance and the influence of different operating conditions.

The system includes an electric water heater, plate heat exchanger, circulation pumps, pipe-in-pipe heat exchanger, air or air-to-water heat exchanger, water tanks, sensors, flow meters, connecting pipes, hoses and valves. These components enable students to perform a range of practical experiments related to liquid heating, heat transfer and heat exchanger operation.

The equipment supports determination of the heat capacity of a liquid by heating a liquid flow, investigation of liquid viscosity at different temperatures according to laminar flow theory, and determination of heat transfer coefficients during fluid flow through a pipe.

It also allows investigation of the transferred thermal power of pipe-in-pipe and shell-and-tube heat exchangers under different heat carrier flow arrangements, as well as determination of the characteristics of an air-to-water heat exchanger. Data can be collected and processed using dedicated software on a laptop.

Designed and manufactured by Atico Export to meet the practical requirements of modern technical education laboratories.

Laboratory Experiments :

• Determination of the heat capacity of a liquid by heating a liquid flow
• Determination of the viscosity of a liquid at different temperatures according to the theory of laminar flow
• Determination of the heat transfer coefficient during the movement of fluid in a pipe
• Determination of the transferred thermal power of a pipe-in-pipe heat exchanger depending on the flow arrangement of heat carriers
• Determination of the transferred thermal power of a shell-and-tube heat exchanger
• Determination of the characteristics of an air-to-water heat exchanger
• Investigation of heat transfer processes in liquids

Power Specifications :

• Power: 2.5 kW
• Voltage: 220 V ±10%
• Frequency: 50 Hz
• Power cable: European standard

Dimensions and Weight :

• Height: 1000 mm
• Width: 600 mm
• Depth: 700 mm

Delivery Set :

• Liquid Heating Engineering laboratory equipment – 1 set
• Laptop connecting cables – 1 set
• Special software – 1 set

• Metal aluminum frame
• Electric water heater
• Plate heat exchanger
• Circulation pumps
• Pipe-in-pipe heat exchanger
• Air or air-to-water heat exchanger
• Water tanks
• Pumps
• Sensors and flow meters
• Connecting pipes, hoses and valves
• Software for collecting and processing experimental data on a laptop
• Equipment supplied as a complete delivery set compatible with the required design and functionality
• All markings, nameplates and inscriptions on the casing in English and/or Russian
