Smallholder Solar Powered Irrigation Submersible Pump Set

Smallholder Solar-Powered Irrigation Submersible Pump Set is a compact submersible pumping system designed for smallholder irrigation applications and suitable for 3.5" wells. The system is powered by solar energy and is designed for efficient pumping of water from water sources into storage tanks.

The system provides a maximum water flow of 1–1.5 m³/hour and a maximum head of 40 m. It is supplied with a 200–300 Wp solar panel and the necessary connection accessories, including DC cables and MCBs.

The pump features a maintenance-free brushless DC motor made of stainless steel (AISI 304) with an IP68-class enclosure and minimum efficiency of 82%. Integrated maximum power point tracking enables efficient utilization of available solar power.

A controlling and monitoring device provides functions such as dry-running protection and remote control. The system also includes a float switch, suspension rope, delivery hose and connection accessories for transferring pumped water into a water tank.

Manufactured by Atico Export with a focus on precision, durability and consistent performance for technical education and practical training applications.

• Smallholder-size submersible pump system for 3.5" wells
• Protection against reverse polarity, overload and over-temperature
• Water flow: 1–1.5 m³/hour maximum
• Head: 40 m maximum
• Solar panel: 200–300 Wp
• DC cables and MCBs included
• Maintenance-free brushless DC motor
• Stainless steel construction, AISI 304
• IP68-class enclosure
• Minimum motor efficiency: 82%
• Controlling and monitoring device
• Dry-running protection
• Remote control function
• Integrated MPPT (Maximum Power Point Tracking)
• Float switch and suspension rope
• 10 m delivery hose pipe
• Connection accessories for pumping water into a water tank
• Minimum 1-year warranty
• After-sales service
